Lub teb tsav tsav tsav tsav yog muaj cov khoom siv qeeb qeeb, lub thawv, thiab ib lub cev muaj zog, lossis ib lub tshuab roj av sib dhos thiab muaj lub cev muaj zog. Nws yog tsav los ntawm lub cav teeb ntawm qee qhov ceev. Cov lus tsa suab ntawm cov kev tsav teb teb teeb ntawm kab rov tav lossis ntsug (lossis hauv ib lub dav hlau tracker txav ib txhij ntawm ob lub dav hlau) yog li lub ntiaj teb lub vaj huam sib luag yeej ib txwm ntsia lub hnub. Raws li cov haujlwm sib txawv ntawm lub hnub thaum nruab hnub, lub hnub ci tracker thiab inclination ntawm lub hnub, yog li maximizing hluav taws xob tsim hluav taws xob los ntawm lub vaj huam sib luag.
Lub teb tsav tsheb ntawm lub hnub ci tracker yog cov kev daws teeb meem uas tso cai rau lub cuab yeej los daws cov teeb meem ntawm kev sib hloov, cov lus tsa suab, thiab fais fab kis.
Lub kaw lus kaw ntawm lub teb tsav tsav hluav taws muab cov kev ua haujlwm zoo sab hauv rau cov bearary bearings nyob rau hauv lub teb me. Feem ntau, cov ntaub ntawv thiab cov ntsaws ruaj ruaj yog siv rau kev tsim kho kom ua tiav cov nyiaj tau IP65 kev tiv thaiv qib. Theem siab ntawm kev tiv thaiv kuj ua kom tau txais cov khoom lag luam ntev dua.
Lub slewing tsav yog tsim nrog tus kheej - xauv cov neeg cuam tshuam hauv cov huab cua zoo xws li nagkas thiab nag.
Cov Ntawv Piav Qhia Ntau Lawm
|
Tus qauv |
Scr9 |
Hom |
Coresun Drive |
|
Iav Ratio |
61:1 |
Cov Zauv Torque (Max.) |
12.2kn.m |
|
Tilting lub sijhawm (max.) |
33.9kn.m |
Tuav lub zog |
38.7kn.m |
|
Li Aric Axial Thauj Kev Ntsuas |
338kn |
Zoo Li Qub Radial Thauj Ntaus Nqi |
135kn |
|
Neeg kho tshuab efficiency |
40% |
Tus kheej - xauv |
Txhim khu kev qha ncaus tus kheej - xauv |
|
Kev nplig |
Tsawg dua los yog sib npaug rau 0.2 degree |
IP chav kawm |
Ms65 |
Cov yam ntxwv ntawm Slewing Tsav
Los ntawm kev saws cov kabmob li nws cov tseem ceeb tivthaiv, kev muag khoom yuav ris tau axial quab yuam, radial quab yuam thiab tilting lub sij hawm ib txhij. Slewing tsav tau siv dav hauv cov shocks dav, txhua hom cranes, cov tshuab raj ua haujlwm nruab hnub, hnub ci tshuab raj thiab cov tshuab hluav taws xob.
Fais thiab planetary gearboxes tuaj yeem tsim raws li cov neeg siv khoom. Slewing tsav muaj qhov zoo rau txuag chaw hauv chaw, max muaj peev xwm thauj khoom hauv kev tsim muaj nyob rau hauv cov nqi compact, ntau lub zog siv txij nkawm.
Phau txhais lus
1) Tilting lub sijhawm torque: torque yog lub nra ntau los ntawm kev deb ntawm txoj haujlwm ntawm kev thauj khoom thiab nruab nrab ntawm slewing cov kabmob. Yog hais tias lub zog tsim los ntawm kev thauj khoom thiab kev deb yog ntau dua li cov neeg ntsuas lub zog tilque torque, tsav tsheb yuav tau ntxeev.
2) Radial Thauj: load ncaj ntsug rau axis ntawm slewing cov kabmob
3) Axial thauj: thauj mus rau lub axis ntawm slewing cov kabmob
4) tuav lub zog: nws yog thim rov qab los. Thaum tsav tau tig rov qab rov qab, thiab ntu tsis puas,
5) Qhov ntau tshaj plaws torque ua tiav yog hu ua tuav lub zog.
6) Tus kheej - xauv cia: tsuas yog thaum thauj, tsav tsheb tsis muaj peev xwm rov qab tig thiab yog li hu tus kheej- xauv.
--Customer tuaj yeem xaiv lub cev muaj zog raws li peb cov twb tsim Slewing tsav txuas qhov ntev.
--Peb tuaj yeem tsim qauv qauv txuas raws cov neeg siv lub cev muaj zog sib txuas.
--Peb tuaj yeem pab muab cov khoom seem nrog cov tsav tsheb hydraulic, DC tsav, AC lub cev muaj zog, stepper lossis servo lub cev muaj zog.
